Satellite Metals & Tubes's core business is the production of AS 2129 T/E Flange for the water and gas distribution network, sewage treatment and fire protection. Furthermore, Satellite Metals & Tubes has built up strong brands supplying valves and controls for water treatment, dams & reservoirs, HVAC, chemical processing, marine and other industrial sectors. Satellite Metals & Tubes products are designed to the major international standards and are sold in more than countries worldwide. When dealing with the Satellite Metals & Tubes expect quality, reliability, functionality and long lifetime in service.
Satellite Metals & Tubes has not just veryfied the design but we also work in the optimization in order to obtain the best possible and most competitive solution in both the technical and commercial aspects.
In that year, the company began manufacturing stainless steel and established divisions for bright bars and for flanges and forging, and started exporting bright bars. Almost every year since then Satellite Metals & Tubes has added a type of AS 2129 T/E Flange to its range, including sections and profiles, fasteners, wire and wire rods.
AS 2129 T/E Flange Specifications
TABLE E
Nominal Bore Size 15 20 25 32 40 50 65# 80 100 125 150# 200# 250 300 350 400 450 500 600
OD OF FLANGE 95 100 115 120 135 150 165 185 215 255 280 335 405 455 525 580 640 705 825
PCD 67 73 83 87 98 114 127 146 178 210 235 292 356 406 470 521 584 641 756
THICKNESS* 6 6 7 8 9 10 10 11 13 14 17 19 22 25 29 32 35 38 48
No BOLTS 4 4 4 4 4 4 4 4 8 8 8 8 12 12 12 12 16 16 16
BOLT SIZE M12 M12 M12 M12 M12 M16 M16 M16 M16 M16 M20 M20 M20 M24 M24 M24 M24 M24 M30
BOLT LENGTH*** 45 45 45 50 50 60 60 60 65 65 70 75 75 90 100 95 100 110 140
WEIGHT Kg SOW 0.3 0.4 0.5 0.6 0.9 1.2 1.3 1.8 2.7 3.9 5.3 7.5 12.1 15.6 26.6 33.6 42.9 55.5 90.3
